Ensure a superior grip by using a specialty screw from the Metalgrip™ Family on your next steel project. Secure metal to metal purlins up to a .210 steel thickness with the self-drill point #3. Use the self-drill point #5 for attaching metal to steel up to .500 thick. Levi’s quick shipping and expert service can provide the quality product you need to keep your job on target.
• Mechanical galvanized
• Self drilling #1, #3, #4, or #5 point
• Available with or without galvanized EPDM washer 15MM
• Fastens metal to metal
• Available in any color
• Ask about in-stock colors for quick shipment
Previous
Next
Metalgrip #3 W/Washer
| Part # | Description | Head Style | Drill Pt | Pcs/Box | Lbs/Box |
|---|---|---|---|---|---|
| 121434SD | #12 - 14 x 3/4" | 5/16" Hex | #3 | 2,500 | 27.96 |
| 12141SD | #12 - 14 x 1" | 5/16" Hex | #3 | 2,500 | 31.33 |
| 1214114SD | #12 - 14 x 1-1/4" | 5/16" Hex | #3 | 2,500 | 35.69 |
| 1214112SD | #12 - 14 x 1-1/2" | 5/16" Hex | #3 | 2,000 | 36.46 |
| 12142SD | #12 - 14 x 2" | 5/16" Hex | #3 | 1,500 | 29.38 |
| 1214212SD | #12 - 14 x 2-1/2" | 5/16" Hex | #3 | 1,000 | 23.92 |
| 12143SD | #12 - 14 x 3" | 5/16" Hex | #3 | 500 | 13.75 |
Stitch W/Washer
| Part # | Description | Head Style | Drill Pt | Pcs/Box | Lbs/Box |
|---|---|---|---|---|---|
| 141478SD | 1/4 - 14 x 7/8" Stitch | 5/16" Hex | #1 | 2,500 | 31.4 |
Metalgrip #3 W/O Washer
| Part # | Description | Head Style | Drill Pt | Pcs/Box | Lbs/Box |
|---|---|---|---|---|---|
| 121434SDNw | #12 - 14 x 3/4" | 5/16" Hex | #3 | 2,500 | 26.2 |
| 12141SDNW | #12 - 14 x 1" | 5/16" Hex | #3 | 2,500 | 24.9 |
| 1214114SDNW | #12 - 14 x 1-1/4" | 5/16" Hex | #3 | 2,500 | 30.0 |
| 1214112SDNW | #12 - 14 x 1-1/2" | 5/16" Hex | #3 | 2,500 | 33.8 |
| 12142SDNW | #12 - 14 x 2" | 5/16" Hex | #3 | 2,000 | 34.4 |
| 1214212SDNW | #12 - 14 x 2-1/2" | 5/16" Hex | #3 | 1,500 | 31.06 |
| 12143SDNW | #12 - 14 x 3" | 5/16" Hex | #3 | 1,000 | 24.3 |
Metalgrip #5 W/Washer
| Part # | Description | Head Style | Drill Pt | Pcs/Box | Lbs/Box |
|---|---|---|---|---|---|
| 1224114SDT5 | #12-24 x 1-1/4" | 5/16" Hex | #5 | 2,500 | 36.34 |
| 1224112SDT5 | #12 - 24 x 1-1/2" | 5/16" Hex | #5 | 2,000 | 31.82 |
| 12241SDT5 | #12 - 24 x 2" | 5/16" Hex | #5 | 1,500 | 29.34 |
Metalgrip #5 W/O Washer
| Part # | Description | Head Style | Drill Pt | Pcs/Box | Lbs/Box |
|---|---|---|---|---|---|
| 1224114SDT5NW | #12-24 x 1-1/4" | 5/16" Hex | #5 | 2,500 | 29.9 |
| 1224112SDT5NW | #12 - 24 x 1-1/2" | 5/16" Hex | #5 | 2,000 | 27.0 |
| 12241SDT5NW | #12 - 24 x 2" | 5/16" Hex | #5 | 2,000 | 26.1 |
Metalgrip #4 W/O Washer Stitch
| Part # | Description | Head Style | Drill Pt | Pcs/Box | Lbs/Box |
|---|---|---|---|---|---|
| 122478SDT4NW | #12 - 24 x 7/8" | 5/16" Hex | #4 | 2,500 | 24.2 |
