T-17
Choose the Zinc Plated Pancake Head to achieve a low-profile, flush finish. T-17 drill points available in multiple lengths. In-stock colors ship quickly or match to your roof color!
• Designed to Fasten Standing Seam Clips
• Fastens Metal to Wood or Metal to Metal
• One Square Driver Bit per Box
• Available in any Color! Ask About In-Stock Colors
| PART # | DESCRIPTION | HEAD STYLE | DRILL PT | PCS/BOX | LBS/BX |
| 101PH17 | #10 x 1" | Phillips/Square | T-17 | 5,000 | 33.9 |
| 10112PH17 | #10 x 1 - 1/2" | Phillips/Square | T-17 | 2,500 | 23.6 |
| 102PH17 | #10 x 2" | Phillips/Square | T-17 | 2,000 | 23.1 |
| SUBSTRATE | PENETRATION | PULL-OUT STRENGTH |
| 3/4" Ply | Full | 464 |
| 1/2" Ply | Full | 306 |
| 7/16" OSB | Full | 228 |
| 2 x Yellow Pine | 1" | 704 |
| 2 x Spruce Pine Fir | 1" | 653 |
| 2 x Spruce Pine Fir | 1 - 1/2" | 1,102 |
| SHEAR | TENSILE | TORSIONAL |
| 1,500 | 1,930 | 70 |
| SUBSTRATE | GAUGE | THICKNESS | PULL-OVER STRENGTH |
| AZ55Galvalume | 29 | .014 | 467 |
| AZ55Galvalume | 26 | .018 | 626 |
| AZ55Galvalume | 24 | .024 | 992 |
Low-Profile
This Ultra-Thin Pancake Head fastener is designed to fasten flush and lay flat without dimpling or showing through the panel. Available in three sizes with a SP drill point and #2 square, low profile head style.
• Designed to Fasten Flush and Lay Flat Without Dimpling or Showing Through the Panel
• Ultra-Thin Pancake Head
• Fastens Metal to Wood
• One Square Driver Bit per Box
| PART # | DESCRIPTION | HEAD STYLE | DRILL PT | PCS/BOX | LBS/BOX |
| 101PHLP | #10 x 1" | #2 Square | Sharp Point | 5,000 | 30.5 |
| 10112PHLP | #10 x 1 - 1/2" | #2 Square | Sharp Point | 2,500 | 26.8 |
| 102PHLP | #10 x 2" | #2 Square | Sharp Point | 2,000 | 23.2 |
| 10212PHLP | #10 x 2 - 1/2" | #2 Square | Sharp Point | 1,500 | 21.0 |
| SUBSTRATE | PENETRATION | PULL-OUT STRENGTH |
| 3/4" Ply | Full | 484 |
| 1/2" Ply | Full | 280 |
| 7/16" OSB | Full | 196 |
| 2 x Yellow Pine | 1" | 677 |
| 2 x Spruce Pine Fir | 1" | 814 |
| 2 x Spruce Pine Fir | 1 - 1/2" | 909 |
| SHEAR | TENSILE | TORSIONAL |
| 1,750 | 2,544 | 83 |
| SUBSTRATE | GAUGE | THICKNESS | PULL-OVER STRENGTH |
| AZ55Galvalume | 29 | .014 | 465 |
| AZ55Galvalume | 26 | .018 | 649 |
| AZ55Galvalume | 24 | .024 | 978 |
300 Series Stainless Steel
Choose Stainless Steel for a low-profile, flush finish. Sharp point screw available in multiple lengths. In-stock colors ship quickly or match to your roof color!
• Designed to Fasten Standing Seam Clips
• Fastens Metal to Wood or Metal to Metal
• One Square Driver Bit per Box
• Available in any Color! Ask About In-Stock Colors
| PART # | DESCRIPTION | HEAD STYLE | DRILL PT | PCS/BOX | LBS/BX |
| 101PHSS | #10 x 1" | #2 Square | Sharp Point | 5,000 | 37.9 |
| 10112PHSS | #10 x 1 - 1/2" | #2 Square | Sharp Point | 2,500 | 25.9 |
| 102PHSSS | #10 x 2" | #2 Square | Sharp Point | 2,000 | 31.8 |
| SUBSTRATE | PENETRATION | PULL-OUT STRENGTH |
| 3/4" Ply | Full | 454 |
| 1/2" Ply | Full | 352 |
| 7/16" OSB | Full | 187 |
| 2 x Yellow Pine | 1" | 689 |
| 2 x Spruce Pine Fir | 1" | 578 |
| 2 x Spruce Pine Fir | 1 - 1/2" | 1,169 |
| SHEAR | TENSILE | TORSIONAL |
| 1,260 | 1,591 | 53 |
53
| SUBSTRATE | GAUGE | THICKNESS | PULL-OVER STRENGTH |
| AZ55Galvalume | 29 | .014 | 394 |
| AZ55Galvalume | 26 | .018 | 65 |
| AZ55Galvalume | 24 | .024 |
920
